Solutions

Six industry scenarios, out of the box

The same platform capabilities, combined per scenario; modules / display boards complete the hardware, delivering solutions in weeks.

Pin configuration: chip pin assignment and peripheral function view

01

Industrial HMI Panels

Pain point: Traditional configuration screens are rigid; changing models means vendor customization — slow and expensive.

  • Replace the config screen with a 7" industrial display board; Modbus RTU/TCP and PROFINET connect by filling parameters
  • Real-time charts/tables/gauges; alarm rules trigger through the rule engine
  • Edit screens by dragging; download via serial/updater — no more vendor lock-in
ModbusPROFINETChart
Algorithm graph editor: power conversion and control algorithm blocks connected

02

Motor Drives & Servo

Pain point: FOC has a steep learning curve; tuning a parameter means recompiling and reflashing, and the HMI is separate work.

  • FOC/SVPWM/SMO/SMC/HFI/PLL observers come as algorithm blocks; connect them into a control law
  • Fixed-point parameters + online tuning in the property panel; UI and control on one board
  • Encoders, soft limits, and trajectory planning complete the motion-control suite
FOCSensorless observerAlgorithm graph
Algorithm graph editor: power conversion and control algorithm blocks connected

03

Digital power

Pain point: Topology control laws are a black box that’s hard to modify, and power state lacks a good UI.

  • Buck/Boost/Buck-Boost CVCC/LLC/PFC/DOB/DPCC control blocks all included
  • GS32 power board reference design: algorithm graphs drive the power stage
  • Voltage/current/temperature shown via the variable manager; CV/CC states clear at a glance
Buck/BoostLLCPFC
Variable manager: variable groups, connection types, and property configuration

04

IoT Terminals

Pain point: Every device cobbles together its own cloud protocol, and JSON integration is tedious and error-prone.

  • MQTT 3.1.1 client + HTTPS fetch, configured visually — fill parameters and go to cloud
  • UDT JSON passthrough: cloud data normalized into variables by schema, bound to widgets via dot paths
  • WiFi signal icon reads RSSI thresholds directly; disconnects never mis-display
MQTTHTTPSUDT
Variable manager: variable groups, connection types, and property configuration

05

Video Intercom / Access Control

Pain point: SIP/WebRTC stacks are costly to build, and encryption vs. quality is hard to balance.

  • Full SIP register/call/hangup stack (RFC3261 transactions + digest auth)
  • WebRTC real-time audio/video, SRTP media encryption, high-quality Opus + G.711 fallback
  • Camera capture + photo album widget — a complete access-control intercom solution
SIPWebRTCSRTP
DD-CAT IDE designer: canvas, component library, project navigation, and property panel

06

Smart Appliances

Pain point: Consumer interactions have many details (keyboard, animations, albums) and hand-writing each UI is slow.

  • Pinyin IME keyboard (6763-character vocabulary + fuzzy pinyin) works out of the box
  • Carousel, chat UI, video player, and Lottie animation — a full consumer widget set
  • Album widget camera UI + WiFi status icons; smart panels come together fast
Pinyin keyboardAlbumVideo playback

Is your scenario not listed?

Tell us your device and protocol; we’ll propose a combination and an evaluation path.
